Commercial Mobile Asphalt Drum Mix Plants

Send Inquiry

Request To Call Back

Commercial Mobile Asphalt Drum Mix Plants

Name: Commercial Mobile Asphalt Drum Mix Plants
Brand: QUALITY ENGINEERS
Price: 5500000 INR
Availability: InStock

Price 5500000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Commercial Mobile Asphalt Drum Mix Plants Specification

Rated Power
Varies with plant capacity (usually 100 kW - 180 kW)

Max Flow Rate
Depends on model, up to 120 TPH

Lifting Height
Not Applicable (Asphalt Plant)

Motor Power
Electric Motor, typically 30 HP to 60 HP (varies by model)

Surface
Painted/Anti Corrosive Coated

Application
Mixing and Production of Hot Asphalt for Road Construction

Lifting Speed
Not Applicable (Asphalt Plant)

Product Type
Mobile Asphalt Drum Mix Plant

General Use
Used for continuous production of hot mix asphalt for road construction and maintenance

Material
Other

Type
Mobile, Drum Mix Type

Capacity
40 TPH to 120 TPH (Tons per hour), Model Dependent

Weight (kg)
Varies with capacity, typically 18,000 kg to 34,000 kg

Computerized
No (Generally semi-automatic or manual, computerization available as option)

Automatic
Yes

Control System
PLC Control

Cooling System
Water or Air cooled system for bitumen tank (optional)

Method
Drum Mix Continuous Process

Voltage
220-440 Volt (v)

Dimension (L*W*H)
Approx. 12m x 2.5m x 3.5m (varies by model)

Feature
Mobile, Durable, High Efficiency, Low Maintenance

Color
Red (Customizable as per client requirements)

Warranty
1 year

Burner Type
Diesel/LDO/Furnace Oil compatible, automatic ignition system

Feeder Arrangement
Individual AC drive, variable speed, adjustable gates

Drum Length
Approx. 4.8m to 7.5m depending on capacity

Fuel Consumption
7 to 15 liters/ton (as per material & capacity)

Asphalt Tank Capacity
15,000 L to 30,000 L

Aggregate Bin Compartments
3 or 4 as per requirement

Filler Unit
Screw conveyor or pneumatic system

Mobility
Mounted on single/double axles for easy transport

Dust Collection System
Dry Dust Collector with Bag Filter/Primary Cyclone

Tyre Arrangement
Pneumatic Tyre for mobility

Control Cabin
Fully insulated, operator-friendly cabin included

Chassis
Heavy duty, modular

Mixing Time
Continuous (Drum Type)

Conveyor System
Inclined load-out conveyor for finished mix

Aggregate Size
Up to 60 mm max. size

Commercial Mobile Asphalt Drum Mix Plants Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Commercial Mobile Asphalt Drum Mix Plants

Mobile Asphalt Drum Mix Plant is extremely cherished in the construction sites for mixing the mineral filler uniformly and producing to make the best output of raw materials. It is controlled with robotic burner to control adverse temperature and bitumen in this drum. This plant is created to attain the maximum efficiency and less heating loss. Mobile Asphalt Drum Mix Plant is made with metallic as well as non-metallic tools to prevent the abrasion resistance barrier easily.

Other Details of Mobile Asphalt Drum Mix Plant

Surface Treatment : Painted
Export Market : Africa, Sudan, All Gulf Countries
Delivery time depend on order location

Product details

Capacity	150 Ton/Hour
Usage/Application	Road Construction
No Of Bins Total Storage	Four
Automation Grade	Automatic
Brand/Make	Quality Engineers
Material	MS
Voltage	440 V
Surface Treatment	Color Coated

Mobility and Robust Design

Our Mobile Asphalt Drum Mix Plants are engineered for easy relocation, mounted on single or double axles with pneumatic tyres to facilitate transport from site to site. The modular, heavy-duty chassis and anti-corrosive painted surface ensure longevity and adaptation to various work environments, making these plants a reliable choice for road contractors requiring on-the-go flexibility.

Efficient Operation and Control

Equipped with PLC automatic control systems, the plant supports precise management of aggregate, filler, and bitumen feed rates. The fully insulated operator cabin enhances working conditions, while individual AC-driven feeders and adjustable gates contribute to accurate aggregate proportioning for optimal asphalt quality. The burner's automatic ignition and variable speed conveyors promote fuel efficiency and user-friendly operations.

Customizable to Project Needs

Recognizing diverse project requirements, we offer multiple burner compatibility (Diesel, LDO, Furnace Oil) and dust collection options such as bag filters or cyclones. The asphalt tanks are available from 15,000 L to 30,000 L, and the plants are capable of handling aggregates up to 60 mm with capacities scaling from 40 to 120 TPH. Color and safety modifications can be tailored for individual client specifications.

FAQ's of Commercial Mobile Asphalt Drum Mix Plants:

Q: How do the burner options in the plant benefit different construction sites?

A: The plant supports Diesel, LDO, or Furnace Oil burners with automatic ignition, ensuring flexibility in fuel choice based on local availability and cost efficiency. This adaptability helps keep operations running smoothly regardless of fuel preference at a specific site.

Q: What is the typical process for producing asphalt in this drum mix plant?

A: Asphalt is produced continuously by feeding aggregates, bitumen, and filler material into a rotating drum. Individual feeders and variable speed conveyors ensure precise component proportioning, while the drum mixes materials uniformly as they move through it, resulting in high-quality hot mix output.

Q: When would a mobile drum mix asphalt plant be ideal for my project?

A: These mobile plants are especially useful for projects requiring frequent relocation or for work in remote locations where transporting hot mix asphalt is challenging. The mobile design allows easy transport and quick setup at different job sites, making them perfect for both road construction and maintenance.

Q: Where can these mobile asphalt plants be deployed effectively?

A: Our modular design and mobility features make these plants ideal for deployment at highway, urban, rural, or infrastructure construction sites across India and internationally-wherever continuous project execution and easy transport between job sites are priorities.

Q: What type of control and automation does the plant offer to operators?

A: The plant boasts a user-friendly, PLC-based control system installed in a fully insulated cabin, ensuring smooth and safe operations. Options for semi-automatic or fully manual control are also available, and computerization upgrades can be provided if requested.

Q: How does the dust collection system enhance operation safety and efficiency?

A: A dry dust collector with optional bag filter or cyclone keeps emissions within regulatory limits and protects the environment during operation, ensuring cleaner sites and compliance with safety standards for both workers and nearby communities.

Q: What are the main benefits of choosing this mobile drum mix asphalt plant?

A: Key benefits include mobility, easy setup and dismantling, user-friendly controls, energy and fuel efficiency, reliability under demanding site conditions, and the ability to handle varying capacities and aggregate sizes. These features contribute to seamless road construction and reduced operating costs.
